Lifting Unit HE-6-N-75-H-0-0-P with dampers
Article number: 000000140112
Manufacturer: Friedemann Wagner GmbH
stroke 75 mm
adjustable stroke
piston diameter 25 mm
hydraulic damper single-sided
end-position monitoring possible
- pneumatic lifting unit
- Linear unit for vertical tasks
- horizontal use possible
- The stop screw is hollow and accommodates the sensor in a space-saving manner
- Bearing: sealed ball bush
- technical data see below
Technical Information: Technical data and illustrations are non-binding. All information is based on an operating pressure of 6 bar, air consumption is understood at 1 bar. We reserve the right to make changes at any time. All information is without guarantee.
Product Images: The original may differ from the product image used.
Choose options
Lifting Unit HE-6-N-75-H-0-0-P with dampers
Technical Information
| Control | 4/2 or 5/2 way valve bistable |
| Article Number | 140112 |
| Version | Normal |
| Damping | Hydraulic |
| Pressure Range | 4-8 bars |
| Compressed Air Connection | M5 |
| Adjustment Range [mm] | 0-75 |
| Weight [kg] | 2.0 |
| Stroke [mm] | 75 |
| Bearing Type | Ball bushing sealed |
| Air Consumption per Cycle [cm³] | 50.0 |
| Retraction Force at 6 bar [N] | 200 |
| Impact Force at 6 bar [N] | 220 |
| Material Guide Shaft | Cf 53 hardened |
| Material Housing | High-strength Al, anodized |
